PE Steel Wire Mesh SkeletonPipe
Steel wire mesh reinforced PE composite pipes feature outstanding advantages including corrosion and abrasion resistance, long service life, smooth scale-free inner wall with low friction coefficient, lightweight for easy transportation and installation, eco-friendly sanitation and safe potable water conveyance.
+8613629118613
Mobile
liuhuixia131@gmail.com
Product Features
1.High pressure resistance
Reinforced with high-tensile steel wire mesh, the pipe outperforms ordinary plastic pipes in pressure bearing capacity.
2.Excellent creep resistance
Superior resistance to creep and stress cracking with high mechanical strength.
3.Balanced rigidity and flexibility
Possesses higher rigidity and impact resistance than conventional solid plastic pipes while retaining proper flexibility of pure PE pipes.
4.Excellent dimensional stability & low linear expansion coefficient
Steel has a linear expansion coefficient of 1.2×10⁻⁵/℃ and polyethylene is 2×10⁻⁴/℃. The composite structure drastically cuts the linear expansion rate of plastic tubing and greatly improves dimensional stability.
5.Delamination-free structure vs sheet-reinforced composite pipes
Specially modified bonding material securely fuses steel and PE uniformly. The mesh structure eliminates the common delamination defect found in metal sheet reinforced plastic composite pipes.
6.Good magnetic traceability
Traceable via magnetic metal detectors to prevent accidental damage during excavation and facilitate emergency repair and routine maintenance.
7.Enhanced flow capacity
Under identical nominal working pressure, the pipe wall is thinner than solid-wall PE water supply pipes, saving raw materials while significantly boosting fluid throughput.
Application Fields
1.Municipal Engineering
Pipes for urban water supply, fire protection, coal gas and natural gas transportation.
2.Industrial Engineering
Process pipes and drainage pipes for conveying corrosive gas, liquid and solid powder in food & pharmaceutical, petrochemical, thermal power and metallurgical & mining industries.
3.Agriculture & Forestry Irrigation
Water delivery pipes for farm irrigation and landscape greening.
4.Expressway
Buried drainage pipes and conduits for electric wires and cables.
5.Ocean Engineering
Seawater conveyance pipelines, submarine pipelines and optical/electric cable conduits.
